The Standing Electric Wheelchair S1 is designed for users who need comfortable powered mobility along with electric standing and reclining functions. It gives the user more flexibility to change position while providing convenient day-to-day movement with a 360° joystick controller.
The S1 features electric standing with gradual position adjustment, allowing the user to move into a standing position in a controlled manner. The backrest can also be electrically reclined, making it easier to find a comfortable position during extended use.
Powered by two 24V 250W DC motors, the wheelchair uses 22-inch rear solid tires and 8-inch PU front wheels for stable movement. Its single-hand 360° omnidirectional joystick allows easy maneuvering and zero-radius turning, making it practical for both indoor and outdoor mobility.
The wheelchair also includes electronic and electromagnetic braking systems, anti-tip wheels and a reinforced steel frame for added stability. The breathable sandwich mesh seat, adjustable headrest, armrests, backrest and leg supports provide flexibility to suit different users.
With its combination of electric standing, reclining and powered mobility, the S1 is particularly suitable for users looking for a standing mobility solution, including applications related to spinal cord injury rehabilitation.
Key Features
- Electric Standing Function – Gradual and infinitely adjustable standing movement.
- Electric Reclining – Allows the backrest to recline for a more comfortable position.
- 360° Joystick Control – Single-hand omnidirectional control for easy manoeuvring.
- Zero-Radius Turning – Helps the wheelchair turn within a small space.
- Dual 250W Motors – 2 × 24V 250W DC motors for powered mobility.
- Electronic + Electromagnetic Brakes – Two braking systems for controlled movement.
- Anti-Tip Wheels – Provides additional stability during standing and movement.
- Breathable Mesh Seat – Sandwich mesh material designed for airflow and moisture management.
- Adjustable Headrest – Provides additional head and neck support.
- Adjustable Armrests & Backrest – Can be adjusted according to user requirements.
- 22-Inch Rear Wheels – Solid rear tires for stable movement.
- 8-Inch PU Front Wheels – Designed for smooth steering and manoeuvrability.
- Steel Frame – Strong main frame construction.
- Careful Position Adjustment – Standing function supports gradual posture adaptation.
Technical Specifications
| Specification | Details |
|---|---|
| Model | S1 |
| Product Type | Standing Electric Wheelchair |
| Main Frame | Steel |
| Functions | Electric Standing, Electric Reclining & Mobility |
| Standing Function | Electric, infinitely adjustable |
| Standing Height | 149 cm |
| Full Reclined Length | 134 cm |
| Motor | 2 × 24V 250W DC Motors |
| Standard Battery | 24V 40Ah Lead-Acid |
| Controller | Single-Hand 360° Omnidirectional Joystick |
| Braking System | Electronic Brake + Electromagnetic Brake |
| Range | 30–100 km* |
| Front Wheels | 8-Inch PU Wheels |
| Rear Wheels | 22-Inch Solid Tires |
| Seat Material | Sandwich Breathable Mesh |
| Seat Width | 42 cm |
| Seat Depth | 43 cm |
| Seat Height from Ground | 55 cm |
| Backrest Width | 42 cm |
| Backrest Height | 43 cm |
| Headrest Width | 30 cm |
| Headrest Height | 30 cm |
| Armrest Inner Width | 49 cm |
| Armrest Outer Width | 58 cm |
| Overall Size (L × W × H) | 107 × 62 × 100 cm |
| Bare Frame Weight | 46 kg |
| Weight with Standard Battery | 70 kg |
| Wooden Case Packaging Weight | 120 kg |
| Wooden Case Size | 104 × 64 × 91 cm |
Order & Delivery
ORDER Us As Soon As Possible (Only Limited products are available)
Contact us on WhatsApp:
+92-323-2088952
Our Location :
Office 106 1st Floor, Al Amna plaza Opp. Capri Cinema, M. A Jinnah road, Karachi.
MSR Surgical Pakistan — Make Your Life Independent
